5

Fuel

50:1 MIXING CHART

GASOLINE

gal.

123 4 5

2-CYCLE

OIL fl. oz.

2.6 5.2 7.8 10.4 13

GASOLINE

liter

1234 5

2-CYCLE OIL

ml

20 40 60 80 100

• Gasoline is very flammable.

Avoid smoking or bringing any

flame or sparks near fuel. Make

sure to stop the engine and allow

it cool before refueling the unit

• The RedMax engines are lubricated

by oil specially formulated for air-

cooled 2-cycle gasoline engine use.

If RedMax oil is not available, use

an anti-oxidant added quality oil

expressly labeled for air-cooled 2-

cycle engine use. (JASO FC

GRADE OIL or ISO EGC GRADE)

RECOMMENDED MIXING RATIO

GASOLINE 50:OIL 1

• Exhaust emission are controlled by

the fundamental engine parameters

and components (eq., carburation,

ignition timing and port timing)

without addition of any major

hardware or the introduction of an

inert material during combustion.

• These engines are certified to

operate on unleaded gasoline.

• Make sure to use gasoline with a

minimum octane number of 90

ROZ(USA/Canada : pump octane

min.87)

• Unleaded gasoline is recommended

to reduce the contamination of the

air for the sake of your health and

the environment.

• Poor quality gasolines or oils may

damage sealing rings, fuel lines or

fuel tank of the engine.
