Storage

Trouble Shooting Guide

Case 1. Starting failure

CHECK PROBABLE CAUSES ACTION

fuel tank incorrect fuel drain and fill with correct fuel

fuel filter fuel filter is clogged clean

carburetor adjustment screw out of normal range adjust to normal range

sparking (no spark) is fouled/wet clean/dry

plug gap is incorrect correct (GAP: 0.6~0.7mm)

spark plug

spark plug disconnected retighten

Case 2. Engine starts but does not keep running/Hard re-starting.

CHECK PROBABLE CAUSES ACTION

fuel tank incorrect fuel or staled fuel drain and fill with correct fuel

carburetor adjustment screw out of normal range adjust to normal range

muffler, cylinder (exhaust port) carbon is built-up wipe away

air cleaner clogged with dust wash

cylinder fin, fan cover clogged with dust clean

When your unit seems to need further service, please consult with the G.E.B.E.

Aged fuel is one of major causes of engine starting failure. Before storing the unit, empt

the fuel tank and run the engine until it uses all the fuel left in the fuel line and the

carburetor. Store the unit indoor taking necessary measures for rust prevention.
