2

• SAFETY FIRST

Instructions contained in warnings within

this manual marked with a

symbol

concern critical points which must be

taken into consideration to prevent

possible serious bodily injury, and for this

reason you are requested to read all such

instructions carefully and follow them

without fail.

_ WARNINGS IN THE MANUAL

This mark indicates instructions which must be

followed in order to prevent accidents which

could lead to serious bodily injury or death.

This mark indicates instructions which must be

followed, or it leads to mechanical failure,

breakdown, or damage.

This mark indicates hints or directions useful

in the use of the product.

Table of Contents

Specifications

Page 2

Symbols on the machine

Page 3

For safe operation

Page 3 & 4

Set up

Page 4

Fuel

Page 5 & 6

Operation

Page 6& 7

Maintenance

Page 8, 9 & 10

Storage

page 11

Troubleshooting guide

Page 11

Specifications

Dry weight with accessories

11.7 lbs (5.3kg)

Engine Type

Air-cooled 2-stroke gasoline

Model

Zenoah GZ25N

Displacement

1.6cu-in (25.4cc)

Max. output

1.2Hp (0.9kW)at 7500/min

-1

(rpm)

Idle speed

3000–200/min

-1

(rpm)

Fuel

Mixture(Gasoline 50 : Oil 1)

Carburetor

Walbro Diaphragm type

Spark plug

NGK CMR7A

Fuel tank capacity

22.0 fl.oz (0.65

)
