The engine exhaust from this product
contains chemicals known to the State
of California to cause cancer, birth
defects or other reproductive harm.
WARNING
OWNER/OPERATOR MANUAL
HANDHELD BLOWER
848-L08-93A1 (501)
HBZ2600
Thank you for purchasing a RedMax
product.
Before using our blower, please read
this manual carefully to understand the
proper use of your unit.
DRIVE UNIT 200101 and up ENGINE UNIT 50200101 and up
APPLICABLE SERIAL NUMBERS :
Page view 0
1 2 3 4 5 6 ... 23 24

Summary of Contents

Page 1 - OWNER/OPERATOR MANUAL

The engine exhaust from this product contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. WA

Page 2 - SAFETY FIRST

 10 again for at least one minute. As someoils may be difficult to agitate dependingon oil ingredients, sufficient agitation isnecessary for the eng

Page 3 - CONTENTS

 11  RESTARTING ENGINE WHILE ENGINE IS HOT1. When restarting the engine immediatelyafter stopping it, leave the choke open. 2. If the engine won&apo

Page 4 - Safety Precautions

 12 2. Use neutral detergent and warm water toclean the filter element. After cleaning, airdry the element completely. Place thefilter element into

Page 5

FUEL FILTER•A clogged fuel filter may cause pooracceleration of the engine. Checkperiodically to see if the filter is cloggedwith dirt. The filter c

Page 6

 14 StorageBEFORE STORING THE BLOWER:1. Drain a fuel tank and push the primer bulbuntil it becomes empty of fuel.2. Remove the spark plug and drop a

Page 7 - Symbols on the machine

Attach the adequate accessories, respectively forblower operation and dust-collecting operation.• Use the gloves during operation.• In adjustment of t

Page 8 - Assembly

Troubleshooting guideCase 1. Starting failure CHECK PROBABLE CAUSES ACTIONfuel tank ➞ incorrect fuel ➞ drain it and with correct fuelfuel filter ➞ fue

Page 9

Parts List NOTE : 1. Use KOMATSU ZENOAH genuine parts as specified in the parts list for repair and/orreplacement. 2. KOMATSU ZENOAH does not warrant

Page 10

Fig.1 ENGINE GROUP HBZ2600 18 Parts List

Page 11 - Operation

Fig.1 ENGINE GROUP HBZ2600Key# Part Number Description Q'ty1 848-F30-12A2 CYLINDER 12 4810-12210 GASKET 13 4820-12130 BOLT TORX, M5x22 24 4810-13

Page 12 - Maintenance

Read this manual carefully to understand allsafety precautions, controls, proper operationand maintenance of your RedMax blower.Failure to do so could

Page 13

Fig.2 BLOWER GROUP HBZ2600 20 Parts List

Page 14

Key# Part Number Description Q'ty1 848-L0F-55A1 VOLUTE CASE 12 T4022-11301 VOLUTE COVER ASSY 13 1600-33130 SCREW 34 T4970-52001 SCREW TORX 125 T4

Page 15 - (Preparing for use)

EMISSION-RELATED PARTS, FOR TWO (2) YEARS FROM THE DATE OF ORIGINAL DELIVERY OF THE UNIT, KOMATSU ZENOAH AMERICA INC. (THE COMPANY), THROUGH ANY RedMa

Page 16 - Troubleshooting guide

Pièces en rapport avec les émissions de gaz d'échappement : KOMATSU ZENOAH AMERICA INC., parl'intermédiaire de n'importe quel revendeur

Page 17 - HANDHELD BLOWER

KOMATSU ZENOAH AMERICA INC.4344 Shackleford Road Suite 500Norcross, Georgia 30093

Page 18

CONTENTSSAFETY PRECAUTIONS················································································ 4OPERATORUSE OF BLOWERWORKING CONDITIONAVOI

Page 19 - Fig.1 ENGINE GROUP HBZ2600

• Read this Blower Owner/OperatorManual carefully. Be sure youunderstand how to operate this unitproperly before you use it. Failure to doso could res

Page 20

• Never use the blower without thescreen at the air intake of the blower.Before each use, check that, thescrew(1) is securely tightened and isfree fro

Page 21 - Fig.2 BLOWER GROUP HBZ2600

 6 • Keep operation area clear of all persons,particularly small children and pets. Injurymay result from flying debris.• Avoid using the blower whe

Page 22 - LIMITED WARRANTY

 7 Symbols on the machineFor safe operation and maintenance, symbols arecarved in relief on the machine. According to theseindications, please be ca

Page 23 - Garantie limitée

Parts Location & SpecificationsAssembly BLOWER PIPE• Align groove in blower pipe with projectionon blower housing (or another blower pipe)and sli

Page 24 - Norcross, Georgia 30093

 9 Fuel RECOMMENDED MIXING RATIOGASOLINE 50:OIL 1• Exhaust emission are controlled by thefundamental engine parameters andcomponents(eq., carburati
